DC10 Single-Door Controller
The DC10 is the foundational hub that connects single doors to the Rhombus Access Control and Security platform, while also serving as a hub for Rhombus Smart Sensors. With enterprise-grade scalability and a compact design built for the tightest spaces, it delivers total cloud-based access control without the complexity.
DC10 Specifications
Controller Parts
Controller, Cover
Universal Mounting Plate
Operating Temperature
32 ˚F - 122 ˚F (0 ˚C - 50 ˚C)
Dimensions
190 x 190 x 41 mm [7.5 x 7.5 x 1.7 in]
Connectivity
Ethernet and Wi-Fi
Weight
1.25 kg [2.76 lb]
In the Box
Screwdriver, required fasteners, input supervision resistors, universal mount plate, and quick install guide
Power Input
PoE PoE+, PoE++ (60/90W); 12 VDC, 3.5 A
PoE Output
PoE, PoE+
Impact Rating
IK08
Mounting Options
Hassle-free, open-bottom cable access for wall, ceiling, or plenum mounting
10-Year Warranty Included
Rhombus Sensor Network Compatible
Relays
1 Wet/ Dry Relay and 1 Dry AUX Relay
Inputs
(4) Supervised / Unsupervised Inputs - REX, DPI, (2) AUX
